Your Leading Slab Moulds Supplier



Fujian Unik Machinery Technology Co., Ltd. was founded in 2010, is a vibrant and mission-driven company specializing in the manufacturing of high-quality brick machines and molds. Our product range includes moulds for paver moulds, block moulds, curb moulds, slab moulds and precast moulds, catering to diverse construction needs. Sincerely look forward to your cooperation.




First 12 Last 1/2

Why Choose Us?

Wide Product Range

At UNIK, we offer an extensive range of high-quality moulds designed to meet diverse construction needs. Our product portfolio includes over 1,200 types of moulds across more than 10 series, catering to various applications in the building and infrastructure sectors.



Advanced Equipment

Our company is equipped with advanced machining capabilities, including German-imported plasma CNC cutting machines and Taiwanese large-scale gantry machining centers. Utilizing state-of-the-art CNC programming and machining processes, we significantly enhance the precision and efficiency of our mould production.

Custom Service

We can also customize moulds for various types of cement bricks based on customer-provided samples or designs. Whether you require unique shapes, sizes, or specialized functionalities, our team is ready to deliver.

Broad Market

We successfully entered international markets, exporting our products to countries like Russia, South Africa, Libya, Oman, Morocco, Philippines, India, Kenya, Ghana and India.



Specifications of Slab Moulds

Hardness for inserts

HRC61-65

Hardness for shoes

HRC59-62

Carburized layer thickness

1.3-1.5mm

Unilateral clearance between presser foot and mold cavity

0.2 mm ≤ Unilateral clearance ≤ 0.4mm

Flatness of the whole board

≤ 0.5mm

Deviation in length and width dimensions of a single cavity model

-0.3 to+0.3mm

The dimensional deviation of the height (filling depth) of the lower model cavity

± 0.5mm



Paving Slab Moulds



Features of Slab Moulds

1.1-1.4mm carburized depth to fend off damage from sharp aggregates.


Exact tolerances (±0.12mm) for slabs that align without issues.


Swappable modules for fast repairs, minimizing breaks in work.


Chrome layers to block rust, holding up for more than 450,000 uses.


Handles 100 tons of compression, suited for thick slabs in high-traffic zones like loading docks.



Customization Options



Shape: Customizable

Size: Customizable

Color: Customizable

MOQ: Customizable



Product Video









Common Materials of Slab Moulds

Steel Molds

These are durable and ideal for mass production, providing a perfect finish and precise dimensions. However, they can be heavy and expensive.

Plastic Molds

Often used for smaller projects or intricate designs, they are lightweight and less costly, making them perfect for reusability in DIY home projects.

Rubber Molds

Known for their flexibility, rubber molds are suitable for detailed work like ornate façade elements. They can be easily stripped off the cured concrete without damaging the piece.



Common Methods for Slab Moulds Texture


Mold Texture Made By Polishing
This method involves using polishing tools and abrasives to gradually remove material from the mold surface, resulting in a smooth and glossy texture. It is commonly used for achieving high-gloss finishes or mirror-like surfaces.



Mold Texture Made By Sandpaper
Sandpaper is used to manually sand the mold surface, creating a texture with a fine, uniform pattern. The coarseness of the sandpaper determines the level of roughness or smoothness of the resulting texture.



Mold Texture Made By Grit Stone
Grit stones, such as silicon carbide or diamond stones, are used to manually grind the mold surface, creating a textured pattern. The type and coarseness of the grit stone determine the texture's characteristics, including its depth and pattern.



Mold Texture Made By Blasting
Abrasive blasting methods, such as sandblasting or bead blasting, involve propelling abrasive particles at high speed onto the mold surface. This process creates a textured pattern by etching or removing material from the surface.



Mold Texture Made By EDM
Electrical Discharge Machining (EDM) utilizes electrical discharges to erode the mold surface and create a precise texture. This method is often used for intricate or complex patterns that are challenging to achieve through other techniques.



Mold Texture Made By Satin
Satin finishes are achieved by applying a soft, non-abrasive material, such as a cloth or pad, to the mold surface. The material is rubbed against the surface in a consistent manner to create a smooth, lustrous texture.


Cooperation Process


Commu Nication Details

Contact online customer service to communicate the details.

Start Designing

Start your prototype design.

Confi Rmation Of The Final Draft

Iterate on details to finalize.

Payment Of Deposit

Factory prepares materi-als and customers make deposits.

Start Of Production

Factory starts produc-tion.

Delivery Receipt

The customer confirms the quality of the goods and receives them.





After-Sales Service
01.

12-Month workmanship warrant.

02.

Spare modular insert kits and re-hardening services.

03.

Installation instructions and best-practice guidance

04.

Remote technical support during system startup.



Packing & Transportation

Packaging Details

Coated with anti-rust oil before packing.

Secured in fumigation-free wooden crates with foam protection.

Payment Terms

T.T with 30% downpayment, 70%before shipment.

Paypal or West Union also accept.

productcate-400-227





FAQ



Q: Do you accept small orders?

A: Whether you require standard moulds for high-volume production or custom designs for specialized projects, we provide tailored solutions backed by modern facilities and international experience.

Q: What processing centers do you use to produce your products?

A: Our dedicated workshop is equipped with high-precision CNC machining centers, German vacuum furnaces, EDM machines, and professional inspection systems.

Q: What products can your molds produce?

A: We specialize in producing moulds for a wide range of blocks, such as pavers, hollow block, plaza bricks, and grass pavers.

Q: How to ensure product quality?

A: Our factory uses CNC centers and welding rigs for repeatable precision. Every mould gets inspected for flatness, dimensional accuracy, and durability.

Q: Why choose our precast moulds?

A: You get moulds that maintain tight tolerances over time, require minimal maintenance, and fit into your production line without guesswork. With our consistent manufacturing and real support, the end result is smooth, dependable output, project after project.

We're well-known as one of the leading slab moulds manufacturers and suppliers in China. Please feel free to wholesale high quality slab moulds made in China here from our factory. Contact us for customized service.

Concrete Paving Slab Moulds, Concrete Slab Mould, slab moulds
