Mould For Hollow Blocks
2.Hardness for shoes:HRC59-62
3.Carburized layer thickness:1.3-1.5mm
4.Unilateral clearance between presser foot and mold cavity: 0.2 mm ≤ Unilateral clearance ≤ 0.4mm
5.Flatness of the whole board: ≤ 0.5mm
Send Inquiry
Product Details ofMould For Hollow Blocks
mould for hollow blocks
What Is a Hollow Block Mould?
A hollow block mould is a steel tool that mounts onto a block machine. It shapes concrete into blocks with predefined cavities – the hollow cores that reduce weight, improve insulation, and lower material costs.
The mould determines critical block characteristics:
Outer dimensions and wall thickness
Core size, shape, and position
Surface finish and edge quality
When the mould is correctly engineered, every block meets specifications. When the mould falls short, production suffers from rejects, downtime, and inconsistent product.
Engineering That Delivers Repeatable Results
UNIK moulds for hollow blocks are manufactured using processes that prioritize precision and longevity.
Steel Selection
We fabricate moulds from 42CrMo steel for standard concrete mixes, with tool steel options for highly abrasive materials. The choice of steel directly affects wear resistance and cavity life.
Heat Treatment
Each mould undergoes carburizing heat treatment. This hardens the surface layer to HRC58-62 while maintaining a tougher core at HRC35-40. The hard surface resists abrasion from concrete aggregates. The flexible core absorbs vibration and resists cracking under repeated impact.
Machining Tolerance
Cavities are machined on CNC equipment to ±0.1mm tolerance. Internal corners receive a 3-5mm radius to eliminate stress concentration points. Surface finish reaches Ra 1.6 or better, allowing clean demoulding without concrete adhesion.
Expected Service Life
Under normal production conditions with standard concrete mixes, UNIK hollow block moulds deliver 80,000 to 100,000 cycles before requiring refurbishment or replacement.
Applications
Hollow block moulds from UNIK serve a range of construction needs:
Load-bearing masonry blocks for residential and commercial buildings
Non-load-bearing partition blocks for interior walls
Foundation blocks requiring consistent dimensions for stacking
Custom cavity configurations for specialized insulation or reinforcement requirements
Block dimensions range from standard 4x8x16 inches (100x200x400mm) up to larger metric sizes, with two or three cavities per mould depending on machine capacity.
Technical Support and Service
UNIK provides support that extends beyond the delivery date:
Installation guidance – procedures for correct mounting and alignment
Troubleshooting assistance – quick diagnosis of demoulding or wear issues
Refurbishment services – re-machining and re-heat treatment for worn moulds
Spare parts availability – replacement pins, liners, and fasteners
Customers receive a 12-month warranty against material and workmanship defects.
Our factory
Manufacturing
Delivery
workshop
Process
Export and Logistics
UNIK has shipped hollow block moulds to block plants in Southeast Asia, the Middle East, Africa, and Russia. Standard lead time is 20 to 25 working days after drawing approval. Moulds are packaged in IPPC-compliant wooden crates with anti-rust treatment and impact-resistant wrapping. Shipping port is FOB Xiamen or Quanzhou.
Contact Information
For inquiries regarding hollow block moulds – including custom sizes, machine-specific fitment, or volume pricing – contact UNIK directly.
